Juice it up with UIKit Dynamics
One of my favorite framework on iOS has to be UIKit Dynamics and not enough people talk about it. But this is going to change today. Let’s build a color palette generator and have some fun with UIKit Dynamics along the way.
Photo by Bharath Kumar on Unsplash
Set up
To get started we need a simple UICollectionView that draws a 4 cells per screen with each cell colored as one of the color of the color palette.
class ViewController: UIViewController {
private static let cellId = "cell-id"
private static let maxPalettes = 24
private let colors: [UIColor] = {
// generate a tetradic color palette by generating a random hue value
// and 4 corresponding colors from that base hue: [h, h+0.25, h+0.5, h+0.75]
(0..<maxPalettes).flatMap { _ in
let hueBase = CGFloat.random(in: 0...1)
let saturation = CGFloat.random(in: 0.5...1)
return (0..<4).map {
UIColor(
hue: hueBase + (CGFloat($0) * 0.25),
saturation: saturation,
brightness: CGFloat.random(in: 0.5...1),
alpha: 1
)
}
}
}()
override func viewDidLoad() {
super.viewDidLoad()
let layout = UICollectionViewFlowLayout()
// each cell is 1/4th the height of screen
layout.itemSize = CGSize(
width: view.bounds.width,
height: view.bounds.height * 0.25
)
layout.minimumInteritemSpacing = 0
layout.minimumLineSpacing = 0
let collectionView = UICollectionView(
frame: view.bounds,
collectionViewLayout: layout
)
view.addSubview(collectionView)
collectionView.register(
UICollectionViewCell.self,
forCellWithReuseIdentifier: Self.cellId
)
collectionView.dataSource = self
collectionView.contentInsetAdjustmentBehavior = .never
collectionView.isPagingEnabled = true
}
}
extension ViewController: UICollectionViewDataSource {
func collectionView(
_ collectionView: UICollectionView,
numberOfItemsInSection section: Int
) -> Int {
return colors.count
}
func collectionView(
_ collectionView: UICollectionView,
cellForItemAt indexPath: IndexPath
) -> UICollectionViewCell {
let cell = collectionView.dequeueReusableCell(
withReuseIdentifier: Self.cellId,
for: indexPath
)
cell.backgroundColor = colors[indexPath.item]
return cell
}
}
Add UIKit Dynamics
The nice and easy way of introducing UIKit Dynamics in a UICollectionView is by subclassing a UICollectionViewFlowLayout and use that subclass to provide the effective layout data to the UICollectionView
class BouncyListLayout: UICollectionViewFlowLayout {
// ...
}
class ViewController: UIViewController {
override func viewDidLoad() {
super.viewDidLoad()
let layout = BouncyListLayout()
// ...
let collectionView = UICollectionView(
frame: view.bounds,
collectionViewLayout: layout
)
// ...
}
// ...
}
Within the BouncyListLayout we first need to initialize a UIDynamicAnimator instance. The idea is it have an UIDynamicAnimator and one UIDynamicBehavior per item. We let the base class UICollectionViewFlowLayout do the heavy lifting of creating the UICollectionViewLayoutAttributes we then simply use this UICollectionViewLayoutAttributes to create the UIDynamicBehavior and let UIDynamicAnimator run the physics simulation and return the data back to UICollectionView.
class BouncyListLayout: UICollectionViewFlowLayout {
lazy var animator = UIDynamicAnimator(collectionViewLayout: self)
override func prepare() {
super.prepare()
setUp()
}
private func setUp() {
// ...
}
override func layoutAttributesForElements(in rect: CGRect) -> [UICollectionViewLayoutAttributes]? {
return animator.items(in: rect).compactMap { $0 as? UICollectionViewLayoutAttributes }
}
override func layoutAttributesForItem(at indexPath: IndexPath) -> UICollectionViewLayoutAttributes? {
return animator.layoutAttributesForCell(at: indexPath)
}
}
This mapping between physics world and the UI world works thanks to the fact that UICollectionViewLayoutAttributes conforms to the protocol UIDynamicItem and UIDynamicAnimator providing convenience methods to work with UICollectionView
class UICollectionViewLayoutAttributes : NSObject, NSCopying, UIDynamicItem {
// ...
}
extension UIDynamicAnimator {
convenience init(
collectionViewLayout layout: UICollectionViewLayout
)
func items(in rect: CGRect) -> [any UIDynamicItem]
func layoutAttributesForCell(
at indexPath: IndexPath
) -> UICollectionViewLayoutAttributes?
}
In our setUp method the simplest and the least performant way is to let the UICollectionViewFlowLayout prepare all the items. We invoke super.layoutAttributesForElements for the entire content size. Then for each item we create a UIAttachmentBehavior that controls the springiness of each item. The spring is anchored to the center of the item.
class BouncyListLayout: UICollectionViewFlowLayout {
// ...
private func setUp() {
guard animator.behaviors.isEmpty else {
// animators already setup - skip
return
}
let items = super.layoutAttributesForElements(
in: CGRect(origin: .zero, size: collectionViewContentSize)
) ?? []
for item in items {
let spring = UIAttachmentBehavior(item: item, attachedToAnchor: item.center)
spring.length = 0
spring.frequency = 1.0
spring.damping = 2.0
spring.frictionTorque = 2.0
animator.addBehavior(spring)
}
}
// ...
}
The final piece of the magic comes from shouldInvalidateLayout, which is invoked whenever the content within the UICollectionView updates. Remember that the UIScrollView works by changing the bounds origin value.
The plan here is to adjust the spring center by a certain offset based on how far it is from the touch point. So, items just under the finger have no spring effect while the items furthest have the most spring effect. And then finally call the animator.updateItem(usingCurrentState: item) to update the animator which would then in turn run the physics simulation for the item
class BouncyListLayout: UICollectionViewFlowLayout {
// ...
override func shouldInvalidateLayout(forBoundsChange newBounds: CGRect) -> Bool {
guard let collectionView else { return false }
let touchPt = collectionView.panGestureRecognizer.location(in: collectionView)
let dy = newBounds.origin.y - collectionView.bounds.origin.y
for behaviors in animator.behaviors {
if let spring = behaviors as? UIAttachmentBehavior,
let item = spring.items.first as? UICollectionViewLayoutAttributes {
let offset = abs(touchPt.y - spring.anchorPoint.y)
let yFactor = offset * 0.0001
item.center = CGPoint(x: item.center.x, y: item.center.y + (dy * yFactor))
animator.updateItem(usingCurrentState: item)
}
}
return true
}
// ...
}
Performance improvements
Now for the last bit, if our UICollectionView has a lot of items, we possibly do not want to load all the springs during setup time but rather on the fly when needed. So we need to get rid of the setUp
class BouncyListLayout: UICollectionViewFlowLayout {
- override func prepare() {
- super.prepare()
- setUp()
- }
-
- private func setUp() {
- guard animator.behaviors.isEmpty else {
- // animators already setup - skip
- return
- }
- let items = super.layoutAttributesForElements(
- in: CGRect(origin: .zero, size: collectionViewContentSize)
- ) ?? []
-
- for item in items {
- let spring = UIAttachmentBehavior(item: item, attachedToAnchor: item.center)
- spring.length = 0
- spring.frequency = 1.0
- spring.damping = 2.0
- spring.frictionTorque = 2.0
- animator.addBehavior(spring)
- }
- }
}
And add spring when needed by keeping track of IndexPath for which the springs have already been added. Notice that we are still getting the UICollectionViewLayoutAttributes from UICollectionViewFlowLayout by invoking the super implementation but still returning the values from the UIDynamicAnimator
class BouncyListLayout: UICollectionViewFlowLayout {
lazy var animator = UIDynamicAnimator(collectionViewLayout: self)
private var indexPaths: Set<IndexPath> = []
private func addSpringIfNeeded(toItem item: UICollectionViewLayoutAttributes) {
if indexPaths.contains(item.indexPath) { return }
let spring = UIAttachmentBehavior(item: item, attachedToAnchor: item.center)
spring.length = 0
spring.frequency = 1.0
spring.damping = 2.0
spring.frictionTorque = 2.0
animator.addBehavior(spring)
indexPaths.insert(item.indexPath)
}
override func layoutAttributesForElements(in rect: CGRect) -> [UICollectionViewLayoutAttributes]? {
guard let items = super.layoutAttributesForElements(in: rect) else {
return nil
}
items.forEach { addSpringIfNeeded(toItem: $0) }
return animator.items(in: rect).compactMap { $0 as? UICollectionViewLayoutAttributes }
}
override func layoutAttributesForItem(at indexPath: IndexPath) -> UICollectionViewLayoutAttributes? {
guard let item = super.layoutAttributesForItem(at: indexPath) else {
return nil
}
addSpringIfNeeded(toItem: item)
return animator.layoutAttributesForCell(at: indexPath)
}
// ...
}
